MiTAC Aowanda Multi-Node Edge Server
The MiTAC Aowanda edge server series feature improved slim design for the central unit (CU) and distributed unit (DU) of 5G virtual radio access network (vRAN) and multi-access edge computing (MEC).
The AD211, one of Aowanda edge server series, is optimized for chassis depth in 2U form factor to support network rack cabinet, and is in compliance with NEBS. The centralized power supply and server node management designs can enhance power efficiency and simplify cable management, and is the best choice for telco infrastructure deployment
| AD1S01 (AD211) Specifications | |||
|---|---|---|---|
| System | Form Factor | 2U Rackmount | |
| Dimension (D x W x H) | 16.92" x 17.32" x 3.39" (430 x 440 x 86.3mm) | ||
| Processor | Q'ty / Socket Type | (1) LGA4189 per sled | |
| Supported CPU Series | 3rd Gen Intel Xeon Scalable Processor | ||
| Thermal Design Power Wattage | Max up to 185W (TDP) | ||
| Memory | Supported DIMM Q'ty | (8) DIMM slots per sled | |
| DIMM Type / Speed | DDR4 RDIMM/LRDIMM 3200 | ||
| Memory channel | 8 Channels per CPU | ||
| Expansion Slots | PCI-E | (1) PCIe Gen 4 x16 slot (FHHL) per sled | |
| Others | (1) OCP3.0 slot Small FormFactor per sled | ||
| Storage | Drive bays | (2) E1.S NVMe SSD bays per sled | |
| M.2 | (2) M.2 22110/2280 (by PCIeG.3 interface) per sled | ||
| Power Supply | Efficiency | 80 plus Platinum | |
| Output Watts / Rating | AC 2000 Watts -48VDC 2000 Watts | ||
| Redundancy | 1+1 | ||
Product Information
- Model #: AD1S01 (AD211)
